Unpacking and Mounting the ACX5048 and ACX5096
Routers
IN THIS SECTION
Unpacking an ACX5000 Router | 102
Mounting an ACX5000 Router in a Rack or Cabinet | 103
Unpacking an ACX5000 Router
The ACX5000 router chassis is a rigid sheet-metal structure that houses the hardware components. An
ACX5000 router is shipped in a cardboard carton, secured with foam packing material. The carton also
contains an accessory box and quick start instructions.
CAUTION: ACX5000 routers are maximally protected inside the shipping carton. Do
not unpack the router until you are ready to begin installation.
To unpack an ACX5000 router:
1. Move the shipping carton to a staging area as close to the installation site as possible, but where you
have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
3. Open the top flaps on the shipping carton.
4. Remove the accessory box and verify the contents against the inventory included in the box.
Table 35 on page 103 lists the inventory of components supplied with an ACX5000 router.
5. Pull out the packing material holding the router in place.
6. Verify the chassis components received:
•
Two power supplies
102
