ACX5048 Router Hardware and CLI Terminology Mapping
Table 5 on page 23 describes the hardware terms used in an ACX5048 router documentation and the
corresponding terms used in the Junos OS command line interface (CLI). Figure 3 on page 24 shows the
port locations of the interfaces.
Table 5: CLI Equivalents of Terms Used in Documentation for an ACX5048 Router
Additional Information
Item in
Documentation
Value (as
displayed in the
CLI)
Description (as
displayed in the
CLI)
Hardware
Item (as
displayed
in the CLI)
“Chassis Physical Specifications
for an ACX5000 Router” on
page 82
Router chassis–ACX5048Chassis
Interface Naming Conventions
Used in the Junos OS
Operational Commands
The router does not
have actual FPCs. In this
case, FPC refers to the
router itself.
Value of n is always
0.
Abbreviated name
of the Flexible PIC
Concentrator (FPC)
FPC (n)
Interface Naming Conventions
Used in the Junos OS
Operational Commands
The router does not
have actual PIC devices;
see entries for PIC 0 for
the equivalent item on
the router.
Value of n is always
0.
Abbreviated name
of the Physical
Interface Card (PIC)
PIC (n)
“ACX5000 Universal Metro
Router Overview” on page 17
Built-in network ports
on the front panel of the
router
PIC 048x10G–6x40G
Port and Interface SpecificationsOptical transceiversn is a value
equivalent to the
number of the port
in which the
transceiver is
installed.
Abbreviated name
of the transceiver
Xcvr (n)
“AC Power Supply for an
ACX5000 Router” on page 65
“DC Power Supply for an
ACX5000 Router” on page 69
AC power supply
DC power supply
n is a value in the
range of 0-1.
Power supplyPower
supply (n)
