Table 19: DC Power Supply LEDs on an ACX5000 Router (continued)
DescriptionStateColorName
An error has been detected in the power
supply. Replace the power supply as soon as
possible. To maintain proper airflow through
the chassis, leave the power supply installed
in the chassis until you are ready to replace
it.
On steadilyAmberFault
AC Power Specifications for an ACX5000 Router
Table 20 on page 73 describes the AC power specifications for an ACX5000 router.
Table 20: AC Power Specifications for an ACX5000 Router
SpecificationItem
Operating range:
•
100 / 240 VAC
AC input voltage
50–60 Hz (all product SKUs)AC input line frequency
•
4.5 A at 100–120 VAC
•
2.0 A at 200–240 VAC
AC input current rating
Typical power consumption
230 WACX5048
315 WACX5096
Maximum power consumption
365 WACX5048
470 WACX5096
SEE ALSO
73
