ACX5048 and ACX5096 Cooling System
IN THIS SECTION
Cooling System and Airflow in an ACX5000 Router | 60
Fan Module LED on an ACX5000 Router | 64
Cooling System and Airflow in an ACX5000 Router
IN THIS SECTION
Fan Modules | 60
Fan Module Status | 63
The cooling system in ACX5000 routers consists of fan modules and a single fan in each power supply.
The number of fan modules vary depending whether the size of the router is 1 U or 2 U high. All routers
can be set up to work in the following airflow direction:
•
Airflow Out (AFO)—Air comes into the router through the vents in the front panel.
This topic describes:
Fan Modules
The fan modules in ACX5000 routers are hot-insertable and hot-removable field-replaceable units (FRUs).
These fan modules are designed for air to enter from the ports to the FRU–Airflow Out. The fan modules
are installed in the fan module slots on the management panel of the router next to the power supplies.
