Figure 12: Management Port LEDs on an ACX5000 Router
4—1— RJ-45 console port (C0N) )Status LEDs
5—2— USB portem1–SFP management Ethernet port (C1)
Cage (socket for either 10/100/1000 Base-T RJ45
SFP or 1GbE fiber SFP)
3—em0–RJ-45 (10/100/1000 Base-T) management
Ethernet port (C0)
Table 9 on page 57 describes the management port LEDs.
