Table 43: Console Port Connector Pinout Information (continued)
DescriptionSignalPin
Receive dataRxD Input6
Data carrier detectCD Input7
Clear to sendCTS Input8
Related
Documentation
Connecting a Devicetoa Management Console by Using an RJ-45 Connectoron page 158•
• Configuring the Console Port Type (CLI Procedure)
USB Port Specifications for an EX Series Switch
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port on all EX Series switches:
•
RE-USB-1G-S
•
RE-USB-2G-S
•
RE-USB-4G-S
CAUTION: Any USB memory product not listed as supported for EX Series
switches has not been tested by Juniper Networks. The use of any
unsupported USB memory product could expose your EX Series switch to
unpredictable behavior. Juniper Networks TechnicalAssistance Center (JTAC)
can provide only limited support for issues related to unsupported hardware.
We strongly recommend that you use only supported USB flash drives.
All USB flash drives used on EX Series switches must have the following features:
•
USB 2.0 or later.
•
Formatted with a FAT or MS-DOS file system.
•
If the switch is running Junos OS Release 9.5 or earlier, the formatting method must
use a master boot record. Microsoft Windows formatting, by default, does not use a
master boot record. See the documentation for your USB flash drive for information
about how your USB flash drive is formatted.
Related
Documentation
EX2200 Switches Hardware Overview•
• EX2300 Switches Hardware Overview
• Rear Panel of an EX3200 Switch
• Rear Panel of an EX3300 Switch
Copyright © 2017, Juniper Networks, Inc.92
EX4200 Switch Hardware Guide
