Virtual Chassis Ports Connector Pinout Information for EX4200 Switches

EX4200 switchesuse a 68-pin connector cableto interconnectswitches to form a Virtual

Chassis. The cable is provided with the switch. Table 51 on page 107 provides the Virtual

Chassis ports (VCPs) connector pinout information.

Table 51: Virtual Chassis Ports (VCPs) Connector Pinout Information

Pin NamePin Number

GNDA1

P1TXP0A2

P1TXN0A3

GNDA4

P1TXP1A5

P1TXN1A6

GNDA7

P1TXP2A8

P1TXN2A9

GNDA10

P1TXP3A11

P1TXN3A12

GNDA13

NCA14

NCA15

GNDA16

NCA17

NCA18

NCA19

NCA20
