Table 48: QSFP+ Network Port Connector Pinout Information (continued)

SignalPin

LPMode_Reset9

VccRx10

SCL11

SDA12

GND13

RX3p14

RX3n15

GND16

RX1p17

RX1n18

GND19

GND20

RX2n21

RX2p22

GND23

RX4n24

RX4p25

GND26

ModPrsL27

IntL28

VccTx29

Vcc130

Reserved31

GND32

97Copyright © 2017, Juniper Networks, Inc.
