Page #126 background imageLoading...
Page #126 background image
Table 50: Uplink Modules Connector Pinout Information (continued)
Pin NamePin Number
SGMIITXPF14
GNDF15
Uplink_Expander_IntrF16
GNDF17
Uplink_P27_LED1F18
GNDF19
POWER (12V)F20
GNDG1
GNDG2
XAUI0_RX1NG3
GNDG4
XAUI0_RX3NG5
GNDG6
XAUI1_RX1NG7
GNDG8
XAUI1_RX3NG9
GNDG10
SRX27NG11
GNDG12
SRX25NG13
GNDG14
GNDG15
GNDG16
Uplink_P25_LED0G17
Copyright © 2017, Juniper Networks, Inc.104
EX4200 Switch Hardware Guide
