Original User Manual | Xion Pedelec 7
2 Composition of the vehicle
Motor
Seatpost
Saddle
Seatpost clamp
(with quick-release
lever or screw)
Pedal
Frame
1. Top tube
2. Seat tube
3. Down tube
Fork
DisplayBattery
(on down tube
or seat tube)
Wheel
Control panel
Handlebar
