Below the diamond, the energy recovery (recuperation) is
displayed. You can set two dierent recuperation levels.
The rst level yields 50% energy recovery, while the sec-
ond yields 100%. In the second level, the maximum pos-
sible energy recovery is achieved.
Energy recovery
7.2.3 Battery charge state indicator
The battery charge state indicator is located to the right of
the centre of the display. Using a stylised battery divided
into four segments, it shows the charge remaining in the
battery. The lower the charge state of the battery, the
fewer segments are displayed.
If the battery charge state falls below a minimum level,
the assistance switches o via the motor. The display
remains active until the battery reaches the lowest pos-
sible charge state.
If you do not use your Pedelec for ten minutes, the system
switches o automatically. If you subsequently want to
ride using the assistance, you will have to switch it back
on using the diamond button.
7.2.4 Remaining range indicator
To the right of the display of the power-assist mode, the
distance in km over which you can still travel with power
assist is displayed. This is the remaining range indicator.
Charge state indicator
1 Battery ll
2 Battery almost empty
1
2
If the conditions of the journey change, for example,
by riding up an incline aer a long, at stretch, the
value displayed can also change at short notice.
Please consider this factor when planning your trips.
You are probably familiar with this eect om the
remaining range indicator of your car. The remaining
range depends on the current battery charge state,
the assist mode which has been set (Boost, Tour, Eco)
and the assist level which has been selected.
7.3 Display symbols
The symbols do not appear on the entire screen, but rather
can be seen on the right-hand side (see grey box in
image).
