26 Original User Manual | Pedelec Impulse 2.0
11 Technical data
MOTOR
Brushless electric motor with gear unit and eewheel
Output 250 W rated output
Gross weight
of electric drive,
battery, control unit
Freewheel motor Backpedal brake motor
11 Ah 15 Ah 12 Ah 17 Ah
6.65 kg 6.75 kg 6.75 kg 6.75 / 6.85 kg
Control via torque sensor and rotational speed sensor in motor and speed sensor (on rear wheel)
IMPULSE LIION DOWN TUBE BATTERY
Voltage 36 V 36 V
Capacity 11 Ah 17 Ah
Energy content 396 Wh 612 Wh
Weight 2.9 kg 2.9 kg
Charging time 3 hours 4.5 hours
Cell 2.25 Ah 3.4 Ah
IMPULSE LIION SEAT TUBE BATTERY
Voltage 36 V 36 V 36 V 36 V
Capacity 11 Ah 12 Ah 15 Ah 17 Ah
Energy content 396 Wh 418 Wh 540 Wh 612 Wh
Weight 2.85 kg 2.5 kg 2.95 kg 2.95 kg
Charging time 4 hours 4 hours 5 hours 6 hours
Cell 2.25 Ah 2.9 Ah 3.1 Ah 3.4 Ah
It is generally permitted for children to be carried
in bike trailers on Pedelecs. Observe the maximum
permitted gross weight of the bike ➠ Chapter 30
“Technical data” of the General User Manual (CD). The
Impulse 2.0 mountain bike is an exception. Bike trail-
ers may not be used on this bike.
