Original User Manual | Xion Pedelec 15
Disconnect the battery om the charger and then connect
it again. If the error message still appears, the battery and
charger must be checked by a specialist dealer.
If used incorrectly, the device may be damaged or
inict injuries.
• Only use the charger in dry rooms.
• Only place the charger in a secure stable position
on a suitable surface.
• Do not cover the charger or place any objects on
it as otherwise it could overheat and catch re.
7 Control panel and display
The Xion Pedelec can be controlled via two elements. The
display is located in the middle of the handlebar. The con-
trol panel can be found on the handlebar grip.
Control panel and display
7.1 Control panel
The three buttons each have dierent nctions depending
on the item of the settings menu in which you are located.
7.1.1 Switching on/o
Press the diamond button to switch the Xion system on.
Aer a few seconds, the welcome screen appears, followed
by the start menu.
From there, you can carry out rther settings ➠
Chapter
7.4 “Programming and settings”.
To switch your Pedelec o, press the diamond button on
the control panel for around two seconds whilst in the
start menu. This will take you to the sub-menu.
Navigate to the item “Shutdown” using the arrow buttons
and conrm using the diamond button.
1 Upper arrow button
2 Diamond button
3 Lower arrow button
1
2
3
