Kalkhoff Pedelec Xion

36 I General User Manual
Hbl(B)
Lever
b
Shiing om a large to a smaller chainring
Press lever b once to move the chain om a large to a
smaller chainring.
Operating the standard rear derailleur shiing lever
Lever
a
starting position
1
2
Shiing om a small to a larger sprocket
To shi by one gear only, push lever a to position 1. To
shi by two gears, push the shiing lever to position 2.
You can shi a maximum of 3 gears using this method.
Lever
b
Shiing om a large to a smaller sprocket
Push once to shi to a smaller sprocket.
Lever
b
Gear shi complete
stroke
Click-in position
Click-in position
Trimming operation
When lever b is operated, there is one click where trim-
ming (the noise prevention mechanism) engages, and a
second stronger click when the gear shi stroke is com-
plete. The noise prevention mechanism no longer clicks
once the trimming operation is complete which means
that only the click-in positions will be heard when shiing
between sprockets.
Chain position
Front derailleur movement
If the chain is on the large chainring and the large sprock-
et, the chain will rub the ont derailleur producing a char-
acteristic noise. When this happens, press lever b lightly
to the point where it clicks, this causes the ont derailleur
to move slightly towards the smaller chainring, thereby
eliminating the noise.
Twist-grip shiers
To shi up or down one gear only, turn the twist-grip shi-
er by one increment forwards or backwards.
Zunehmende
Pedalkraft
Zunehmende
Pedalkraft
Abnehmende
Pedalkraft
Abnehmende
Pedalkraft
increasing
pedal force
increasing pedal force
reducing pedal force
reducing pedal
force
If you wish to shi up or down several gears at once, con-
tinue turning the shiing lever by the required number of
shi positions and in the required direction.
