64 I General User Manual
Overview of torques, values apply for standard screws
SCREW CONNECTION THREAD
TIGHTENING TORQUE NM
General
Crank arm, steel M8x1 30
Crank arm, alu M8x1 30
Pedal 9 / 16" 30
Axle nuts, ont gen. 25
Axle nuts, rear gen. 30
Stem expander bolt wedge M8 23
Stem, A-head, angle adjustment M6 10
Stem, A-head, handlebar clamping xture M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14
Stem, A-head, head tube M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14
Bar end, outer clamp M5 / M6 M5: 5 / M6: 10
Seatpost, clamp M8 20
Seatpost, clamp M6 10
Seatpost, saddle clamping bracket M7 / M8 M7: 14 / M8: 20
Front derailleur clamp M5 5
Brake, pad M6 10
Brake, cable clamp M6 10
Sidewall dynamo, xing M6 10
Derailleur hanger M10x1 16
Bottom bracket BSA
according to manufacturer's instructions
Disc brake calliper, Shimano, IS and PM M6 6 to 8
Disc brake calliper, AVID, IS and PM M6 8 to 10
Disc brake calliper, Magura, IS and PM M6 6
Shiing lever clamp M5 5
Brake lever clamp M5 5
V-brake, fastening screw M6 10
Road bike brake M6 10
Freewheel fastening screw n. a. 40
Cassette, lock ring n. a. 30
Handles, screw-on type M4 / M5 M4: 3 / M5: 5
Carbon Carbon ame, saddle clamp M5 / M6 5
Carbon ame, water bottle holder M5 5
Carbon ame, ont derailleur clamp M5 4
Carbon handlebar, shiing lever clamp M5 3
Carbon handlebar, brake lever clamp M5 3
Carbon handlebar, handlebar clamp M5 5
Carbon handlebar, stem clamp M5 / M6 5
