KEB COMBIVERT F4-F Applications Manual

6 11
KEB COMBIVERT F4-F
22
Name: Basis
17.06.99
Chapter
Section Page Date
© KEB Antriebstechnik, 1999
All Rights reserved
Functional Description Positioning Module
Position setting (Pd ) - Parameter
set 0 123456
Pd. 0 Positioning 1111111on
Pd. 1 Manual start 0000000no manual starting
Pd. 2 Kp position 20 20 20 20 20 20 20
Pd. 3 Limit for position controller 500 500 500 500 500 500 500
Pd. 5 S curve time 0,1 0,5 0,5 0,5 2 0,5 0,5
Pd. 6 Acceleration time 0,2 0,8 0,8 0,8 2 0,8 0,8
Pd. 7 Maximum speed 1000 2000 2200 2200 2200 2200 2200
Pd .8 Position setting sign 0 : + 0 : + 1 : - 1 : - 1 : - 1 : - 0 : +
Pd. 9 Position setting high 10 7555110 setting see reference point
Pd. 10 Position setting low 0 5000 0 0 0 5000 0
Pd .11 Positioning mode 01111110 : absolute / 1 : relative
Pd. 12 Target window size 16383 16383 16383 16383 16383 16383 16383 target window 90°
Digital inputs (di) - Parameter
di. 3 Input function I1 19 : Start positioning
di. 4 Input function I2 10 : Start reference point run
di. 5 Input function I3 12 : Reference point switch
di. 6 Input function I4 15 : RST
di. 7 Input function IA 1 : SET
di. 8 Input function IB 1 : SET
di. 9 Input function IC 1 : SET
di. 11 Input function I5 16 : Limit switch right
di. 12 Input function I6 17 : Limit switch left
di. 17 Strobe-dependent 1792 : IA + IB + IC
di. 18 Selection Strobe signal 16 : I1
Digital outputs (do) - Parameter
do. 3 Switching condition 3 30 : Position reached
do. 4 Switching condition 4 1 : Generally on
do. 28 Output filter 1 time 4 ms
do. 30 Output filter 1 linkage 4 : do.4
Satz 0 1 2 3 4 5 6
do. 13 Selection switch. condition Out A do.4 0 do.4 0 do.4 0 0
do. 14 Selection switch. condition Out B 0 do.4 do.4 0 0 do.4 0
do. 15 Selection switch. condition Out C 0 0 0 do.4 do.4 do.4 0
Free-to-program parameter (Fr) - Parameter
Fr. 2 Source parameter set 2 : Terminal binary-coded
