KEB COMBIVERT F4-F Applications Manual

13
ANTRIEBSTECHNIK
4
313
KEB COMBIVERT F4-F
Name: Basis
15.12.98
4
CP - Parameter
© KEB Antriebstechnik, 1998
All Rights reserved
Operation
Chapter Section PageDate
Offset REF 1
Makes it possible to shift the speed setpoint curve.
Adjustment Range: -100…+100 %
Resolution: 0,1 %
Factory setting: 0 %
Customer setting: ________ %
Examples:
Curve 1: CP.16 = 0% (Standard adjustment)
0V = 0 rpm
Direction of rotation "forward": n
max
is reached at +10V
Direction of rotation "reverse": n
max
is reached at -10 V
Curve 2: CP.16 = -40%
0V = -40 % of n
max
"forward"
Direction of rotation "forward": n
max
is reached at 60% of +10V
Direction of rotation "reverse": maximum 60% of n
max
possible
Curve 3: CP.16 = +70%
0V = 70 % of n
max
"reverse"
Direction of rotation "forward": maximum 30% of n
max
possible
Direction of rotation "reverse": n
max
is reached at 30% of -10V
n
max
"reverse"
70 %
2)
1)
3)
-10 V
n
max
"forward"
-4 V
40 %
+10 V
+7 V
