17
ANTRIEBSTECHNIK
4
317
KEB COMBIVERT F4-F
Name: Basis
15.12.98
4
CP - Parameter
© KEB Antriebstechnik, 1998
All Rights reserved
Operation
Chapter Section PageDate
Output Condition OUT D2
1) Only during closed-loop operation (CP.32 = 1) !
Hysteresis
of the torque level : 5% of M
N
motor adjusted in the factory
(see page 23)
of the speed level : 10 rpm
Parameter CP.22 determines the output condition of digital output D2 (terminal
X2.9). ! see table below !
Adjustment Range: 0…33
Resolution: 1
Factory setting: 18
Customer setting: ________
Value D1 and D2 Switching conditions
0 always inactive
1 always active
2 ready for operation; no malfunction (operating state: ready)
3 ready for operation; control release (terminal X2.1) given;
modulation enabled (operating state: run)
4 abnormal operating state or error (status A.xx or E.xx)
5 error (only status E.xx)
6 - reserved -
7 after the motor positive temperature coefficient is triggered
8 - reserved -
9 current controller restricted
1)
10 speed controller restricted
1)
11 any controller restricted
1)
12 acceleration ramp active
13 deceleration ramp active
14 constant run
15 drive runs with contstant speed > speed 0
16 forward – not with noP, LS, Abnormal Stopping or error
17 reverse – not with noP, LS, Abnormal Stopping or error
only digital output D1 only digital output D2
18 - reserved - actual speed > speed level
19 - reserved - - reserved -
20 torque > torque level
1)
- reserved -
21 - reserved -
22 - reserved -
23 - reserved -
24 overload prewarning: overload counter > 80 %
25 overload prewarning: overload counter > 40 %
26 prewarning: "heat sink temperature"
27 - reserved - speed reference displ. > speed level
28 - reserved - system deviation > speed level
1)
29 overload 2 - prewarning (refer to Instruction Manual Part 2)
30 - reserved -
31 - reserved -
32 - reserved -
33 Fault signal; Inverter has disabled the modulation after an error or
fast stop and automatic restart is not activated for the respective error.
