Operation
Chapter Section PageDate
Adjusts the direction of rotation of the encoder.
Adjustment Range: 0…1
Resolution: 1
Factory setting: 0
Customer setting ________
0=track not exchanged
1 = track exchanged
Change Encoder 1 Rotation
This parameter determines the reaction of the drive, to terminal X2.3 (F) and/or X2.4
(R). These terminals can be programmed as software limit switches. The reaction of
the drive is shown in the table below.
Adjustment Range: 0…6
Resolution: 1
Factory setting: 6
Customer setting: ________
Reaction to Limit Switch
Value Error / Status Response of the drive
massage
0 E.PrF modulation immediately switched off
E.Prr ! To restart remove error and activate Reset !
1 A.PrF quick stop / modulation switched off
A.Prr after speed 0 is reached
! To restart remove error and activate Reset !
2 A.PrF quick stop / holding tourqe at speed 0
A.Prr ! To restart remove error and activate Reset !
3 A.PrF modulation immediately switched off
A.Prr ! Automatic restart, when error is no longer
present !
4 A.PrF quick stop / modulation switched off
A.Prr after speed 0 is reached
! Automatic restart, when error is no longer
present !
5 A.PrF quick stop / holding tourqe at speed 0
A.Prr ! Automatic restart, when error is no longer
present !
6 keine no effect on the drive
! Fault is ignored !
Quick stop
⇒⇒
⇒⇒
⇒ deceleration at the torque limit (CP.9)
