KEB COMBIVERT F4-F Applications Manual

Parameter
51
KEB COMBIVERT F4-C
8
Name: Basis
Chapter
Section Page Date
© KEB Antriebstechnik, 1999
All Rights reserved
21.06.99
Fr 3 parameter set lock 2703 - ✓✓ 0 255 1 0 –– 6.7.6
Fr 4 parameter set setting 2704 - ✓✓ 071 0–– 6.7.5
Fr 5 parameter set activation delay 2705 ✓ - ✓ 0,000 10,000 0,001 0,000 sec 6.7.7
Fr 6 parameter set deactivation delay 2706 ✓ - ✓ 0,000 10,000 0,001 0,000 sec 6.7.7
Fr 9 bus parameter set 2709 - - ✓ -1 7 1 0 –– 6.7.3, 6.7.4
Fr 10 load motor dependent parameter 270A - ✓✓ 021 0–– 6.5.4
An - Parameter Addr.
min
max
default
[?] see Page(s)
An 1 noise filter REF 2801 - - ✓ 0 10 1 3 ( 1ms) –– 6.2.6
An 2 zero clamp REF 1 2802 - - ✓ 0,0 10,0 0,1 0,2 % 6.2.9
An 3 REF 1 gain 2803 - - ✓ -20,00 20,00 0,01 1,00 –– 6.2.6
An 4 REF 1 offset X 2804 - - ✓ -100,0 100,0 0,1 0,0 % 6.2.6
An 5 REF 1 offset Y 2805 - - ✓ -100,0 100,0 0,1 0,0 % 6.2.6
An 8 zero clamp REF 2 2808 - - ✓ 0,0 10,0 0,1 0,2 % 6.2.9
An 9 REF 2 gain 2809 - - ✓ -20,00 20,00 0,01 1,00 –– 6.2.6
An 10 REF 2 offset X 280A - - ✓ -100,0 100,0 0,1 0,0 % 6.2.6
An 11 REF 2 offset Y 280B - - ✓ -100,0 100,0 0,1 0,0 % 6.2.6
An 13 AUX function 280D ✓✓ ✓ 051 0–– 6.4.5, 6.4.9, 6.8.9
An 14 analog out1 function 280E ✓✓ ✓ 061 2–– 6.2.10
An 15 analog out1 gain 280F ✓ - ✓ -20 20 0,01 1,00 –– 6.2.11
An 16 analog out1 offset X 2810 ✓ - ✓ -100,0 100,0 0,1 0,0 % 6.2.11
An 18 analog out2 function 2812 ✓✓ ✓ 061 0–– 6.2.10
An 19 analog out2 gain 2813 ✓ - ✓ -20,00 20,00 0,01 1,00 –– 6.2.11
An 20 analog out2 offset X 2814 ✓ - ✓ -100,0 100,0 0,1 0,0 % 6.2.11
di - Parameter Addr.
min
max
default
[?] see Page(s)
di 0 noise filter digital 2900 - - ✓ 0,0 20,0 0,1 0,5 ms 6.3.5
di 1 NPN/PNP selection 2901 - ✓✓ 0 : pnp 1 : npn 1 0 : pnp –– 6.3.3
di 2 input logic 2902 - ✓✓ 0 127 1 0 –– 6.3.5
di 3 input function I1 2903 - ✓✓ 0221 4–– 6.3.7, 6.1.4, 6.11.10
di 4 input function I2 2904 - ✓✓ 0221 5–– 6.3.7, 6.1.4, 6.11.10
di 5 input function I3 2905 - ✓✓ 0221 3–– 6.3.7, 6.1.4, 6.11.10
di 6 input function I4 2906 - ✓✓ 0221 15–– 6.3.7, 6.1.4, 6.11.10
di 7 input function IA 2907 - ✓✓ 0221 0–– 6.3.7
di 8 input function IB 2908 - ✓✓ 0221 0–– 6.3.7
di 9 input function IC 2909 - ✓✓ 0221 0–– 6.3.7
di 10 input function ID 290A - ✓✓ 0221 0–– 6.3.7
di 11 input function I5 290B - ✓✓ 0221 16–– 6.10.4, 6.11.10
di 12 input function I6 290C - ✓✓ 0221 17–– 6.10.4, 6.11.10
di 15 select signal source 290F - ✓✓ 0 127 1 0 –– 6.3.5
di 16 digital input setting 2910 - ✓✓ 0 127 1 0 –– 6.3.5
di 17 input strobe dependance 2911 - ✓✓ 0 4095 1 0 –– 6.3.6
di 18 select strobe source 2912 - ✓✓ 0 4095 1 0 –– 6.3.6
di 19 select strobe mode 2913 - ✓✓ 011 0–– 6.3.6
do - Parameter Addr.
min
max
default
[?] see Page(s)
do 0 output logic 2A00 ✓✓ ✓ 0 255 1 0 –– 6.3.15
do 1 output condition 1 2A01 ✓✓ ✓ 0351 20–– 6.3.10
do 2 output condition 2 2A02 ✓✓ ✓ 0351 18–– 6.3.10
do 3 output condition 3 2A03 ✓✓ ✓ 0351 2–– 6.3.10
do 4 output condition 4 2A04 ✓✓ ✓ 0351 0–– 6.3.10
do 5 output condition 5 2A05 ✓✓ ✓ 0351 0–– 6.3.10
do 6 output condition 6 2A06 ✓✓ ✓ 0351 0–– 6.3.10
do 7 output condition 7 2A07 ✓✓ ✓ 0351 0–– 6.3.10
do 8 output condition 8 2A08 ✓✓ ✓ 0351 0–– 6.3.10
do 9 select out 1 condition 2A09 ✓✓ ✓ 0 255 1 1 –– 6.3.14
do 10 select out 2 condition 2A0A ✓✓ ✓ 0 255 1 2 –– 6.3.14
do 11 select out 3 condition 2A0B ✓✓ ✓ 0 255 1 4 –– 6.3.14
do 13 select out A condition 2A0D ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 14 select out B condition 2A0E ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 15 select out C condition 2A0F ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 16 select out D condition 2A10 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 17 out 1 condition logic 2A11 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 18 out 2 condition logic 2A12 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 19 out 3 condition logic 2A13 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 21 out A condition logic 2A15 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 22 out B condition logic 2A16 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 23 out C condition logic 2A17 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 24 out D condition logic 2A18 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 25 output condition connection 2A19 ✓✓ ✓ 0 255 1 0 –– 6.3.14
do 26 output filter 1 mode 2A1A ✓✓ ✓ 021 0–– 6.3.12
do 27 output filter 2 mode 2A1B ✓✓ ✓ 021 0–– 6.3.12
do 28 output filter 1 time 2A1C ✓✓ ✓ 0 488 1 0 ms 6.3.12
do 29 output filter 2 time 2A1D ✓✓ ✓ 0 488 1 0 ms 6.3.12
do 30 filter 1 condition connection 2A1E ✓✓ ✓ 081 0–– 6.3.12
do 31 filter 2 condition connection 2A1F ✓✓ ✓ 081 0–– 6.3.12
LE - Parameter Addr.
min
max
default
[?] see Page(s)
LE 4 speed level 1 2B04 ✓ - ✓ 0,0 9999,5 0,5 0,0 rpm 6.3.11
*) dependent by the inverter size
