KEB COMBIVERT F4-F Applications Manual

7
ANTRIEBSTECHNIK
5
Parameter
5
1
7
KEB COMBIVERT F4-C
Name: Basis
Section PageDate
© KEB Antriebstechnik, 1999
All Rights reserved
Chapter
21.06.99
ud 8 watchdog time 2608 - ✓✓ 0 : off 10,00 0,01 0 : off sec 11.2.3
ud 13 CP0 address 260D - - - –– –– 1 –– –– 6.12.5
ud 14 CP0 set definition 260E - - - –– –– 1 –– –– 6.12.5
ud 15 CP1 address 260F - ✓✓ -1 : off 7FFF 1 2001 (ru. 1) –– 6.12.4
ud 16 CP1 set definition 2610 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 17 CP2 address 2611 - ✓✓ -1 : off 7FFF 1 2000 (ru. 0) –– 6.12.4
ud 18 CP2 set definition 2612 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 19 CP3 address 2613 - ✓✓ 0 7FFF 1 2009 (ru. 9) –– 6.12.4
ud 20 CP3 set definition 2614 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 21 CP4 address 2615 - ✓✓ 0 7FFF 1 2019 (ru.25) –– 6.12.4
ud 22 CP4 set definition 2616 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 23 CP5 address 2617 - ✓✓ 0 7FFF 1 2002 (ru. 2) –– 6.12.4
ud 24 CP5 set definition 2618 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 25 CP6 address 2619 - ✓✓ 0 7FFF 1 2004 (ru. 4) –– 6.12.4
ud 26 CP6 set definition 261A - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 27 CP7 address 261B - ✓✓ 0 7FFF 1 300B (sP.11) –– 6.12.4
ud 28 CP7 set definition 261C - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 29 CP8 address 261D - ✓✓ 0 7FFF 1 300C (sP.12) –– 6.12.4
ud 30 CP8 set definition 261E - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 31 CP9 address 261F - ✓✓ 0 7FFF 1 2D06 (Cs. 6) –– 6.12.4
ud 32 CP9 set definition 2620 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 33 CP10 address 2621 - ✓✓ 0 7FFF 1 3005 (sP. 5) –– 6.12.4
ud 34 CP10 set definition 2622 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 35 CP11 address 2623 - ✓✓ 0 7FFF 1 3016 (sP.22) –– 6.12.4
ud 36 CP11 set definition 2624 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 37 CP12 address 2625 - ✓✓ 0 7FFF 1 2D00 (Cs. 0) –– 6.12.4
ud 38 CP12 set definition 2626 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 39 CP13 address 2627 - ✓✓ 0 7FFF 1 2D01 (Cs. 1) –– 6.12.4
ud 40 CP13 set definition 2628 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 41 CP14 address 2629 - ✓✓ 0 7FFF 1 2419 (dr.25) –– 6.12.4
ud 42 CP14 set definition 262A - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 43 CP15 address 262B - ✓✓ 0 7FFF 1 2214 (Pn.20) –– 6.12.4
ud 44 CP15 set definition 262C - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 45 CP16 address 262D - ✓✓ 0 7FFF 1 2804 (An.4) –– 6.12.4
ud 46 CP16 set definition 262E - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 47 CP17 address 262F - ✓✓ 0 7FFF 1 2802 (An. 2) –– 6.12.4
ud 48 CP17 set definition 2630 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 49 CP18 address 2631 - ✓✓ 0 7FFF 1 280E (An.14) –– 6.12.4
ud 50 CP18 set definition 2632 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 51 CP19 address 2633 - ✓✓ 0 7FFF 1 280F (An.15) –– 6.12.4
ud 52 CP19 set definition 2634 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 53 CP20 address 2635 - ✓✓ 0 7FFF 1 2813 (An.19) –– 6.12.4
ud 54 CP20 set definition 2636 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 55 CP21 address 2637 - ✓✓ 0 7FFF 1 2A01 (do. 1) –– 6.12.4
ud 56 CP21 set definition 2638 - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 57 CP22 address 2639 - ✓✓ 0 7FFF 1 2A02 (do. 2) –– 6.12.4
ud 58 CP22 set definition 263A - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 59 CP23 address 263B - ✓✓ 0 7FFF 1 2B14 (LE.20) –– 6.12.4
ud 60 CP23 set definition 263C - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 61 CP24 address 263D - ✓✓ 0 7FFF 1 2B05 (LE. 5) –– 6.12.4
ud 62 CP24 set definition 263E - ✓✓ 0 8 (A) 1 0 –– 6.12.4
ud 63 CP25 address 263F - ✓✓ 0 7FFF 1 2400 (dr. 0) –– 6.12.4
ud 64 CP25 set definition 2640 - ✓✓ 08 : A1 0–– 6.12.4
ud 65 CP26 address 2641 - ✓✓ 0 7FFF 1 2401 (dr. 1) –– 6.12.4
ud 66 CP26 set definition 2642 - ✓✓ 08 : A1 0–– 6.12.4
ud 67 CP27 address 2643 - ✓✓ 0 7FFF 1 2402 (dr. 2) –– 6.12.4
ud 68 CP27 set definition 2644 - ✓✓ 08 : A1 0–– 6.12.4
ud 69 CP28 address 2645 - ✓✓ 0 7FFF 1 2403 (dr. 3) –– 6.12.4
ud 70 CP28 set definition 2646 - ✓✓ 08 : A1 0–– 6.12.4
ud 71 CP29 address 2647 - ✓✓ 0 7FFF 1 2404 (dr. 4) –– 6.12.4
ud 72 CP29 set definition 2648 - ✓✓ 08 : A1 0–– 6.12.4
ud 73 CP30 address 2649 - ✓✓ 0 7FFF 1 240C (dr.12) –– 6.12.4
ud 74 CP30 set definition 264A - ✓✓ 08 : A1 0–– 6.12.4
ud 75 CP31 address 264B - ✓✓ 0 7FFF 1 270A (Fr.10) –– 6.12.4
ud 76 CP31 set definition 264C - ✓✓ 08 : A1 0–– 6.12.4
ud 77 CP32 address 264D - ✓✓ 0 7FFF 1 2D17 (Cs.23) –– 6.12.4
ud 78 CP32 set definition 264E - ✓✓ 08 : A1 0–– 6.12.4
ud 79 CP33 address 264F - ✓✓ 0 7FFF 1 2F0B (ds.11) –– 6.12.4
ud 80 CP33 set definition 2650 - ✓✓ 08 : A1 0–– 6.12.4
ud 81 CP34 address 2651 - ✓✓ 0 7FFF 1 241D (dr.29) –– 6.12.4
ud 82 CP34 set definition 2652 - ✓✓ 08 : A1 0–– 6.12.4
ud 83 CP35 address 2653 - ✓✓ 0 7FFF 1 2218 (Pn.24) –– 6.12.4
ud 84 CP35 set definition 2654 - ✓✓ 08 : A1 0–– 6.12.4
ud 85 CP36 address 2655 - ✓✓ 0 7FFF 1 280D (An.13) –– 6.12.4
ud 86 CP36 set definition 2656 - ✓✓ 08 : A1 0–– 6.12.4
ud 92 position display mode 265C - ✓✓ 0 : off 1 : on 1 0 ––
Fr - Parameter Addr.
min
max
default
[?] see Page(s)
Fr 0 copy pararameter set (key) 2700 ✓✓ ✓ -2 : init 7 1 0 –– 6.7.3, 6.12.3
Fr 2 parameter set source 2702 - ✓✓ 031 0–– 6.7.5
*) dependent by the inverter size
