ru-Parameter
2010h
1
-
-
40950
Adr.
min max
default
2011h
1
-
-
2550
ru.16 Internal input state
Display of the currently set external and internal digital inputs. The input is considered as set when it is available as
active signal for further processing (i.e. acceptance by strobe, edge triggering or logic operation). According to following
table a certain decimal value is given out for each digital input. If several inputs are set then the sum of their decimal
values is displayed.
Bit -No. Decimal value Input (standard program) Terminal
0 1 ST (control release) X2.1
1 2 I4 (Reset) X2.2
2 4 I5 (rotation Forward) X2.3
3 8 I6 (rotation Reverse) X2.4
4 16 I1 (prog. input 1) X2.5
5 32 I2 (prog. input 2) X2.6
6 64 I3 (prog. input 3) X2.7
7 128 no function
8 256 IA (internal input A) none
9 512 IB (internal input B) none
10 1024 IC (internal input C) none
11 2048 ID (internal input D) none
( ) - Standard setting
ru.17 Internal output state
With parameters do.1…do.8 switching conditions can be selected which serve as basis for the setting of the outputs.
This parameter indicates which of the selected switching conditions are met, before they are linked by the programmable
logic or inverted. According to following table a certain decimal value is given out for the parameters do.1…do.8. If
several of the switching conditions selected with these parameters are met, then the sum of the decimal values is
displayed.
Bit -No. Decimal value Output
0 1 Switching condition 1 (do.1)
1 2 Switching condition 2 (do.2)
2 4 Switching condition 3 (do.3)
3 8 Switching condition 4 (do.4)
4 16 Switching condition 5 (do.5)
5 32 Switching condition 6 (do.6)
6 64 Switching condition 7 (do.7)
7 128 Switching condition 8 (do.8)
