KEB COMBIVERT F4-F Applications Manual

13
ANTRIEBSTECHNIK
6
113
16.03.99
KEB COMBIVERT F4-F
Name: Basis
6
Functional Description
© KEB Antriebstechnik, 1999
All Rights reserved
Chapter Section PageDate
Adr.
min max
default
Adr.
min max
default
Adr.
min max
default
2019h
0,1
A
-
0
Adr.
min max
default
201Bh
0,1
°
-
360,0-360,0
Adr.
min max
default
201Ch
0,5
rpm
-
9999,5-9999,5
201Dh
1
°C
-
1000
ru-Parameter
ru.29 Heat sink temperature
ru.29 shows the actual heat sink temperature of the inverter.
201Ah
ru.26 Actual speed master
0,5
rpm
-
9999,5-9999,5
Shows the actual motor speed of the drive connected to the encoder interface 2 (X5).
Precondition: Encoder line number (dr.30) and rotation of encoder (dr.34) are adjusted correctly.
ru.25 Peak apparent current
ru.25 allows the detection of short-time peaks of the motor current within an operating cycle. For that the highest
detected value of ru.9 is stored. The peak value memory is cleared by pressing the keys UP or DOWN or by bus by
writing any chosen value to the address of ru.25. A disconnection of the inverter also results in a clearing of the
memory.
ru.27 Angular deviation
Display of the angular displacement between setpoint position and actual position in the positioning and synchronous
operation.
ru.28 Speed deviation
Display of speed droop between actual speed of the master and actual speed of the slave (independent of rotation
direction).
Positive speed values: The master drive rotates faster than the slave drive.
Negative speed values: The slave drive rotates faster than the master drive.
unit-dependent
