GB - 71
Dimensions and weights
5.5 Dimensions and weights
5.5.1 Dimensions air cooling system mounted version
453
960
935
300
340
M10 / 4x
B
B
A
A
R6
Figure 22: Fan heat sink Weight per module
A-heatsinkairow,B-insideventilation 97.5 kg
