Parameter summary
7.3 Parameter summary
TheCPparametersareoneoftheparameterselectiondenedbyKEB.Youneedanapplica-
tion manual in order to get access to the entire parameters.
Display
Parameter Setting range Resolu-
tion
Factory
setting
Origin
CP.00 password input 0…9999 1 – ud.01
CP.01 status display – – – ru.00
CP.02 actual line frequency – 0.1 Hz – ru.03
CP.03 AC current L1 – 0.1 A – ru.08
CP.04 AC current L2 – 0.1 A – ru.09
CP.05 AC current L3 – 0.1 A – ru.10
CP.06 act.DC utilization – 1 % – ru.13
CP.07 peak DC utilization
peak value
– 1 % – ru.14
CP.08 DC current – 0.1 A – ru.15
CP.09 DC voltage – 1 V – ru.19
CP.10 peak DC voltage – 1 V – ru.20
CP.11 power module temperature – 1 °C – ru.38
CP.12 OL counter display – 1 % – ru.39
CP.13 actual power – 0.1 kW – ru.81
CP.14 total regen – 0.1 kWh – ru.82
CP.15 total motor – 0.1 kWh – ru.83
CP.16 total net – 0.1 kWh – ru.84
CP.17 actual net – 0.1 kVA – ru.85
CP.18 ANOUT 1 / gain ±20.00 0.01 1.00 An.33
CP.19 comparison level ±30000.00 V 0.01 V 600.00 V LE.00
CP.20 general fault reset 0…10 1 3 Pn.15
CP.21 last error – – – In.21
CP.22 last error -1 – – – In.21
CP.23 last error -2 – – – In.21
CP.24 last error -3 – – – In.21
CP.25 last error -4 – – – In.21
CP.26 last error -5 – – – In.21
CP.27 last error -6 – – – In.21
CP.28 last error -7 – – – In.21
CP.29 software version 1.11 – 1.11 In.06
CP.30 software date 0801.7 – 0801.7 In.07
CP.32 puls off level 0.0…-1000.0 kW 0.1 kW -0.8 kW cS.06
CP.33 operating mode 0…3 1 0 Pn.19
CP.34 regeneration level 100…120 % 1 % 103 % cS.02
