Connection of the control board version S
6.5 Connection of the control board version S
6.5.1 Assignment of the control terminal strip X2A
10 11 12 13 14 15 16 17 18 19 20 21
22 23 24 25 26 27 28 29
X2A
Conductor cross-section 0.14…1.5 mm², tightening torque 0.22...0.25 Nm
PIN Function Name Default Description Specications
10 24V input Uin External supply of the control
board
21.6...26.4 V DC
/ 1 A
11 Mass COM Reference potential
12 Digital input 1 ST Control release / reset
Ri:4.4kΩ
13 Digital input 2 I1 Set selection programmable
14 Digital input 3 I2 Set selection programmable
15 Digital input 4 I3 Ext. error programmable
16 Digital input or output I/O
(I4)
Activesignal(connectionof
all R6 at parallel operation in
master-slavemode)
17 24 V output Uout Voltage supply for in- and
outputs
approx. 24 V /
max. 100 mA
18 Mass COM Reference potential
19 Digital output 1 O1 DC >600 V Transistoroutput(DC>
CP.19)
Imax:25mA
20 Digital output 2 O2 Error mes-
sage
Transistoroutput(errormes-
sage)
Imax:25mA
21 Analog output AN-
OUT
Difference to mains frequency
(CP.18)
0…±10 V / max.
5 mA
22 24 V output Uout see terminal 17
23 Mass COM Reference potential
24 Relay 1 / NO contact RLA Ready for
operation
(noerror)
Relay output
Readysignal(status"Stb"or
"rEGEn")
max. 30 V DC *)
0.01…2 A DC25 Relay 1 / NC contact RLB
26 Relay 1 / switching
contact
RLC
27 Relay 2 / NO contact FLA DC > 600 V
Relayoutput(DC>CP.19)
max. 30 V DC *)
0.01…2 A DC
28 Relay 2 / NC contact FLB
29 Relay 2 / switching
contact
FLC
*)Therelayoutputsmustbeoperatedwithmax.48VDCprotectiveseparationvoltagetoguaran-
tee the CE standard. After consultation KEB a current of max. 2A DC is permissible for 120 V AC
(dependingontheswitchingcapacityetc.).
