GB - 88

Connection of the control board version S

6.5.2 Assignment of the socket X2B

RJ45 socket for phase synchronization

and temperature sensor

No. Name Function

1 8

1 T1 Connection for temperature sen-

sor(option)

2 T2

3 U13_syn Synchronization phase 1 / 3

4 – reserved

5 U21_syn Synchronization phase 2 / 1

6 – reserved

7 U32_syn Synchronization phase 3 / 2

8 – reserved

Figure 37: RJ45 socket

Theconnectionismadewithasynccable1:1withthesocketX2B,X2CorX2Datthecom-

mutation reactor or synchronisation unit.

6.5.3 Assignment of the terminal block X2C

24 25 26

Conductor cross-section 0.14…1.5 mm², tightening torque 0.22...0.25 Nm

PIN Function Description

24 Bridge between pin

24 and pin 25

Activation of the self-holding of the line contactor

26 not assigned -
