GB - 73
Dimensions and weights
5.5.3 Radiointerferencelter(side-mounted)
260
235
210
300
390
240
A
INVERTER
3x480V +5% AC/50-60Hz
HF-FILTER
30.E4.T60-1001
KEB Automation KG
D-32677 Barntrup
650A @ T=45 C
HPF:-25 C - +85 C
LINE
6xø12
PEPE
d d
Mat.-Number
U
rated
I
rated
P
V
Interference
level/
Line length
Height A Weight
[V] [A] [W]
[mm]
[kg]
15E4T60-1001 3x400/480 650 60 C2 / 30 m 135 14
Technical data of the connection terminals
Maximum tightening torque
PE M12 M10 stay bolt for ring thimble 48 Nm 400 lb inch
d Ø8
Hole for screw M12 for max. two ring thimbles each with 240 mm²
Figure 24: Radio interference lter (side-mounted)
5.5.4 Synchronization unit
171
144
48
77
20
M4M6
8
12
Ø8
Mat.-Number 00R6940-2408 Weight 0.65 kg
Technical data of the connection terminals Maximum tightening torque
PE M12
Stay bolt for ring thimble
1.3 Nm 12 lb inch
PE M12 4.5 Nm 40 lb inch
Figure 25: Synchronization unit
