GB - 97
Special adjustments
7.5 Special adjustments
The power supply and regenerative unit can be adapted to the application with the following
parameters.
No. Name r/w Enter Origin
CP.18 ANOUT 1 gain yes – An.33
The analog output displays the difference between actual supply frequency and set supply
frequency. At factory setting of CP.18 this corresponds to 1 V per 0.1 Hz difference. The dis-
play occurs with right sign. The reference value of 50 or 60 Hz is determined during power
on.
Setting range Setting Meaning
0…±20.00 1.00
Theamplicationtothedesiredoutputvoltagecanbe
adaptedwithCP.18.Max.possible:±10V.
No. Name r/w Enter Origin
CP.19 comparison level 0 yes – LE.00
This parameter determines the switching level for transistor output O1, as well as relay
output 2.
Setting range Setting Meaning
0…3200.00 V 600.00 V
The switching condition is fullled and the transistor
output is set if the DC voltage level exceeds the ad-
justed value in CP.19. Relay output 2 is set, if the load
shunt relay is additionally tightened.
No. Name r/w Enter Origin
CP.20 general fault reset yes – Pn.15
A general fault reset can be activated with this parameter. Atten-
tion, the machine manufacturer must observe appropriate protective
measures for operators staff and machine.
Setting range Setting Meaning
0
3
No general fault reset.
1…10
Maximum errors, which are reset within one hour. If the
number of errors per hour exceeds the adjusted value
in CP.20, only a manual reset via terminal strip can be
made.
