KEB combivert R6-S User Manual

GB - 70
Technical Data
5.3 Accessories
Unit size 29
Rated voltage 400 V
Commutation reactor
29Z1B04-1000
125%max.short-termoverload(regenerativemode)
125%max.short-termoverload(supplymode)
Synchronization unit
00R6940-2408
Control cabinet installation; max. distance to the commuta-
tionchokeorharmoniclter1m
Patch cable
00F50C3-4010
Length 1 m
for connection of the synchronization unit with R6 regenera-
tive unit
5.4 Options
Unit size 29
Mainslter
30E4T60-1001 in accordance with EN 61800-3
LimitclassC2(onlywithferriterings)
LimitclassC1(onconsultationwithKEB)
DC fuses
1000 V/500 A Mat.no. 009025H-3679 or
750V/500AMat.no.0090249-5679(twoparallelforeach)
Harmoniclter
29Z1C04-1000
Theoverloadcurrentreducesatcertainmainsconditions!
Please contact KEB for data to the THD value at regenera-
tive operation in accordance with EN 61000-2-12.
Operators Digital operator, interface operator
Bus operators
CAN,ProBus,InterBus,Ethercat,Ehternet,Sercos,Mod-
Bus, PROFINET, Devicenet, HSP5
5.4.1 Ferrite rings
Ferrite rings are used for the reduction of the cable-based and radiated interferences. For a
high damping, the ferrite rings are attached as close as possible to the interference source,
i.e. at the DC and at the motor output terminals of the frequency inverter. The conductors
must passed through the ferrite core for the use as current-compensated choke. PE must be
passed outside. Further information can be taken from the provided documentation. Which
ferrite ring shall be used is dependent on the used cable cross-section.
Part number Nominal size in mm Inside diameter in mm
0090396-2621 R 42/26/18 24.9
0090390-5241 R 56/32/18 29.5
0090395-3820 R 63/38/25 36.0
0090395-5222 R 87/54/30 54.5
0090395-5520 R 102/66/15 64.5
