GB - 101
Appendix A
A.2 DC link capacitors of KEB frequency inverters
Frequency inverter COMBIVERT F5
200 V units 400 V units
Unit size Capacity Unit size Capacity
05 780 µF 05 180 µF
07 880µF(940µF*) 07 180µF(300µF*)
09 1080 µF 09 300 µF
10 1080 µF 10 345 µF
12 2220 µF 12 470 µF
13 3280 µF 13 580 µF
14 4100 µF 14 650 µF
15 4100 µF 15 940 µF
16 5040 µF 16 1290 µF
17 9900 µF 17 1640 µF
18 13200 µF 18 1875 µF
19 15600 µF 19 2700 µF
20 16500 µF 20 3900 µF
21 19800 µF 21 4950 µF
22 4950 µF
23 6350 µF
24 8400 µF
25 9900 µF
26 11700 µF
27 14100 µF
28(P)/28(W) 16200 / 19800 µF
29(P)/(W) 19800 / 23400 µF
30 28200 µF
31 32900 µF
32-35 39600 µF
36 59400 µF
* Special unit
The precharge circuit must be taken for COMBIVERT F5 inverters from the re-
spective power circuit manual.
