KEEWAY FACT 50 4T - Page 108

108
Disassembly and Installation of Engine
1 engine stationary axis M12×1.25×280 2 bolt M10×1.25×40 3 seat steel rope 4 bolt M8×31 5 rear shock
absorber assembly 6 engine assembly 7 rear wheel assembly 8 rear brake rocker arm assembly
A
torque force of engine
stationary axis 1: 55-
62N·m
B
torque force of bolt 2:
37-44N·m
C
torque force of bolt4:
22-29N·m
