K-MIX EDITOR
101
• Turn clockwise to increase the frequency; turn counterclockwise to decrease the
frequency.
• A specic value may be entered into the accompanying number box as an alternative
way of setting the frequency.
• Range: 3kHz – 20kHz
CUT/BOOST KNOB & NUMBER BOX
The cut/boost knob controls the amount of cut or boost the high-shelf lter will apply.
• Turn clockwise to increase (boost); turn counterclockwise to decrease (cut).
• A specic value may be entered into the accompanying number box as an alternative
way of setting the cut/boost level.
• Range: ±18dB
COMPRESSOR SECTION
The Compressor section of the channel strip is home to the compressor
parameters. Each of the 8 input channels (and the main output bus) have
their own downward compressor available for taming those out of control
peaks.
BYPASS BUTTON
The bypass button enables or disables the compressor.
• Clicking the button will toggle the state of the bypass.
• The button will light up green when enabled (compressor on).
• The button will go dark when disabled (compressor bypassed).
THRESHOLD KNOB & NUMBER BOX
The threshold knob controls the volume level at which the compressor
will engage.
• Turn clockwise to increase (higher threshold); turn counterclockwise to decrease (lower
threshold).
• A specic value may be entered into the accompanying number box as an alternative way
of setting the threshold.
• Range: -70dB – +10dB
• When the effect is enabled, any audio above the threshold will cause the compressor to
engage. Audio below the threshold will pass through unaltered.
MAKEUP GAIN KNOB & NUMBER BOX
The makeup gain knob controls the amount of makeup gain applied to the output of the
compressor. This allows you to increase the overall level of the signal after it has been
compressed; it “makes up” for the gain reduction.
0.00 dB
24.00 dB
10 ms 50 ms
10.00
Thresh Ratio
Attack Release
COMPRESSOR
Makeup Gain
