K-MIX EDITOR
100
CUT/BOOST KNOB & NUMBER BOX
The cut/boost knob controls the amount of cut or boost the low-shelf lter will apply.
• Turn clockwise to increase (boost); turn counterclockwise to decrease (cut).
• A specic value may be entered into the accompanying number box as an alternative
way of setting the cut/boost level.
• Range: ±18dB
MID
The EQ’s middle band is a fully parametric bandpass lter, sporting controls for frequency, gain,
and Q (bandwidth).
FREQUENCY KNOB & NUMBER BOX
The mid frequency knob controls the center frequency of the mid-band EQ.
• Turn clockwise to increase the frequency; turn counterclockwise to decrease the
frequency.
• A specic value may be entered into the accompanying number box as an alternative
way of setting the frequency.
• Range: 200Hz – 6kHz
CUT/BOOST KNOB & NUMBER BOX
The cut/boost knob controls the amount of cut or boost the mid-band EQ will apply.
• Turn clockwise to increase (boost); turn counterclockwise to decrease (cut).
• A specic value may be entered into the accompanying number box as an alternative
way of setting the cut/boost level.
• Range: ±18dB
Q KNOB & NUMBER BOX
The Q knob controls the amount of Q (or “bandwidth”) for the mid-bandpass lter.
• Turn clockwise to increase (narrower bandwidth); turn counterclockwise to decrease
(wider bandwidth).
• A specic value may be entered into the accompanying number box as an alternative
way of settings the Q.
• Range: 0.1 – 10
HI
The EQ’s higher band is a sweepable, dual-pole, high-shelving lter.
FREQUENCY KNOB & NUMBER BOX
The high frequency knob controls the center frequency of the high-shelf lter.
