16-6 Return to Section Topics 6482-901-01 Rev. A / August 2012
Section 16: SCPI Command Reference Model 6482 Dual-Channel Picoammeter / Voltage Source Reference Manual
Table 16-3
FORMat command summary
Command Description
Default
parameter SCPI
:FORMat
:SREGister <name>
:SREGister?
[:DATA] <type>[<,length>]
[:DATA]?
:BORDer <name>
:BORDer?
:ELEMents
[:SENSe[1]] <item list>
[:SENSe[1]]?
:CALCulate <item list>
:CALCulate?
:TRACe <item list>
:TRACe?
:SOURce3 <name>
:SOURce3?
Select data format for reading status event registers
(ASCii, HEXadecimal, OCTal or BINary).
Query format for reading status event registers.
Specify data format (ASCii, REAL, 32 or SREal).
Query data format.
Specify byte order (NORMal or SWAPped).
Query byte order.
Specify data elements (CURRent[1], CURRent2,
TIME, and STATus).
Query data format elements.
Specify CALCulate elements (CALCulate, TIME,
or STATus).*
Query CALC data elements,
Specify TRACe data elements: CURRent[1],
CURRent2, CALCulate1, CALCulate2,
CALCulate3, CALCulate4, CALCulate5,
CALCulate6, CALCulate7, TIME, STATus, ALL,
DEFault (CURRent[1], CURRent2).
Query TRACe elements.
Specify SOURce3 data format (ASCii,
HEXadecimal, OCTal, or BIN).
Query SOURce3 data format.
ASCii
ASCii
Note
CURR1,
CURR2
CALC
DEFault
ASCii
9
9
9
9
9
Note: *RST default is NORMal. :SYST:PRES default is SWAPPed.
*This command specifies data elements for CALC1 through CALC7.
Table 16-4
OUTPut command summary
Command Description
Default
parameter
SCPI
:OUTPut[1]
[:STATe] <b>
[:STATe]?
:ENABle
[:STATe] <b>
[:STATe]?
:TRIPped?
:OUTPut2
[:STATe] <b>
[:STATe]?
Path to control output 1.
Turn source 1 on or off.
Query state of source 1.
Path to control output enable:
Enable or disable output enable for both sources.
Query state of output enable.
Output enable tripped?: 1 (no) or 0 (yes).
Path to control output 2.
Turn source 2 on or off.
Query state of source 2.
OFF
OFF
OFF
9
9
9
9
9
9
