Model 6482 Dual-Channel Picoammeter / Voltage Source Reference Manual Section 17: Calibration
7. Send the following command to output 0 V:
:SOUR2:VOLT 0
8. Note and record the DMM reading, and then send that value as the parameter for the following
command:
:CAL:PROT:SOUR2 <DMM_Reading>
9. Send the following command to output -10 V:
:SOUR2:VOLT -10
10. Note and record the DMM reading, and send that value as the parameter for the following
command:
:CAL:PROT:SOUR2 <DMM_Reading>
11. Repeat steps 4 through 10 for the 30 V range using Table 17-13 as a guide. Be sure to:
• Select the 30 V range using the :SOUR2:VOLT:RANG 30 command.
• Send the ±30 V source values where appropriate.
12. Send this command to turn off the channel 1 output:
:OUTP2 OFF
Table 17-13
Channel 2 remote voltage bias calibration summary
Voltage bias
range
Calibration
voltages Calibration commands
10 V
+10 V
0 V
-10 V
:OUTP2 ON
:SOUR2:VOLT:RANG 10
:SOUR2:VOLT 10
:CAL:PROT:SOUR2 <DMM_Reading>
:SOUR2:VOLT 0
:CAL:PROT:SOUR2 <DMM_Reading>
:SOUR2:VOLT -10
:CAL:PROT:SOUR2 <DMM_Reading>
30 V
+30 V
0 V
-30 V
:SOUR2:VOLT:RANG 30
:SOUR2:VOLT 30
:CAL:PROT:SOUR2 <DMM_Reading>
:SOUR2:VOLT 0
:CAL:PROT:SOUR2 <DMM_Reading>
:SOUR2:VOLT -30
:CAL:PROT:SOUR2 <DMM_Reading>
:OUTP2 OFF
