KERN PES 620-3M User Manual

TPES-B_TPEJ-B-BA-e-2319 82
Data type
T1 - T6 = 1 - 6 characters
For PEJ:
T1
T2
T3
T4
T5
T6
Code
Significance
T1
T2
T3
T4
T5
T6
Sp
Sp
Sp
Sp
Sp
Sp
20H
20H
20H
20H
20H
20H
Net weight (not tared)
N
Sp
Sp
Sp
Sp
Sp
4EH
20H
20H
20H
20H
20H
Net weight (tared)
T
O
T
A
L
Sp
54H
4FH
54H
41H
4CH
20H
Total
G
Sp
Sp
Sp
Sp
Sp
47H
20H
20H
20H
20H
20H
Gross weight
U
N
I
T
Sp
Sp
55H
4EH
49H
54H
20H
20H
Piece weight
*Sp = space
For PES:
T1
T2
T3
T4
T5
T6
Code
Significance
T1
T2
T3
T4
T5
T6
Sp
Sp
Sp
Sp
Sp
Sp
20H
20H
20H
20H
20H
20H
Net weight
T
O
T
A
L
Sp
54H
4FH
54H
41H
4CH
20H
Total
G
Sp
Sp
Sp
Sp
Sp
47H
20H
20H
20H
20H
20H
Gross weight
U
N
I
T
Sp
Sp
55H
4EH
49H
54H
20H
20H
Piece weight
*Sp = space
Numeric data:
D1 – D12: 1 – 12 characters
D1-D12
Code
Significance
+
2BH
0 or positive data
-
2DH
Negative data
0 – 9
30H – 39H
Numbers 0 to 9
0 also used for zero padding
.
2EH
Decimal point (position not fixed)
[
5BH
Number between brackets „ [ “ and “ ] “ marks the
non-relevant digit for verification
]
5DH
Sp
20H
Space before numeric data
If numeric data does not contain a decimal point, a
space is output at the least significant digit and no
decimal point is output
*Sp = space
