19.5 Formats of the data output (special format 2)
These data formats are only available for the PES weighing system.
19.5.1 Data composition
Consists of 14 characters, including the end characters (CR= 0DH, LF= 0AH) *.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
S1
S2
S3
Sp
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
Sp
U1
U2
U3
CR
LF
Status
Blank
Measurement data (incl. polarity and decimal
point)
Blank
Unit
End
characters
* End characters: CR = paragraph, LF = line
19.5.2 Data description
Status:
S1, S2, S3 = 3 characters
S1
S2
S3
Code (S1)
Code (S2)
Code (S3)
Significance
S
Sp
S
53H
20H
53H
Data are stable
S
Sp
D
53H
20H
44H
Data are instable
Numeric data:
10 characters, right justified
D1-D10
Code
Significance
-
2DH
Negative data
0 – 9
30H – 39H
Numbers 0 to 9
.
2EH
Decimal point (position not fixed)
Sp
20H
Space before numeric data
If numeric data does not contain a decimal
point, a space is output at the least significant
digit and no decimal point is output
/
2FH
Separator character inserted to the left of the
non-verification-relevant digit
*Sp = space
