[SENSe:]{FREQuency|PERiod}:VOLTage:RANGe {<range> | MIN | MAX | DEF} [, (@<ch_list>)]
[SENSe:]{FREQuency|PERiod}:VOLTage:RANGe? [{(@<ch_list>) | MIN | MAX | DEF}]
Selects a fixed voltage range for frequency and period measurements.
Parameter is shared between frequency and period measurements. Setting or querying the parameter with
the FREQuency version of this command is identical to setting or querying it with the PERiod version.
Parameter Typical return
<range>: {100 mV|1 V|10 V|100 V|300 V}.
Default: 10 V
+1.04530000E+03
Configure frequency measurements, and select 10 VACrange.
CONF:FREQ
FREQ:VOLT:RANG 10
–
The input signal for frequency or period measurements has an AC voltage component. Use this command to
select a fixed voltage range for frequency and period measurements.
Use [SENSe:] {FREQuency|PERiod}:VOLTage:RANGe:AUTO to disable or enable voltage autoranging or use
CONFigure:{ FREQuency|PERiod} to select voltage autoranging by default.
–
Selecting a fixed range ([SENSe:]<function>:RANGe) disables autoranging.
–
If the input signal is greater than can be measured on the specified fixed range, the instrument displays Overload
on front panel and returns "9.9E37" from the remote interface. Autoranging can be enabled for the input
voltage.
– This parameter is set to its default value after a Factory Reset (*RST command).
Keysight DAQ970A/DAQ973A Programming Guide 237
2 SCPI Programming
