188 E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Frequency, Hardware, and Personality Options
Frequency, Hardware, and Personality Options
This section lists the options available with an Keysight E8257D/67D, E8663D
PSG signal generator.
Table 2-1
Frequency Options
503 100 kHz to 3.2 GHz frequency range (E8663D Only)
509 100 kHz to 9 GHz frequency range (E8663D Only)
513 250 kHz to 13 GHz frequency range (E8257D/67D Only)
520 250 kHz to 20 GHz frequency range (E8257D/67D Only)
521 10 MHz to 20 GHz frequency range (E8257D Only)
532 250 kHz to 32 GHz frequency range (E8257D/67D Only)
540 250 kHz to 40 GHz frequency range (E8257D Only)
544 250 kHz to 44 GHz frequency range (E8267D Only)
550 250 kHz to 50 GHz frequency range (E8257D Only)
567 250 kHz to 67/70 GHz frequency range (E8257D Only)
Table 2-2
Hard ware Options
1E1 Adds output step attenuator for extended range to −135dBm (E8257D and E8663D Only)
1EA (Discontinued) Adds high RF output power +20dBm at 20 GHz, +14 dBm at 40 GHz (E8257D Only)
1ED Specifies Type–N RF output connector (20 GHz models only)
1EH Adds improved harmonics
1EM Moves all front panel connectors to rear panel
1EU High output power (E8257D and E8663D)
1SM Adds scan modulation (E8257D and E8663D)
UNR (Discontinued)/UNX Adds enhanced close–in phase noise
UNT Adds AM/FM modulation
UNW Adds fast pulse < 3.2 GHz
UNY Adds enhanced ultra-low phase noise
003 Adds digital outputs to DSIM (E8267D Only)
004 Adds digital inputs to DSIM (E8267D Only)
005 (Discontinued) Adds 6 GB hard drive (Option 601/602 required) (E8267D Only)
