E8257D/67D, E8663D PSG Signal Generators Service Guide 209
Replaceable Parts
Cables
Cables
This section lists part numbers for the cables in your signal generator.
Table 2-4
Reference Designator Input Output Part Number
A1W1
a
Ribbon Cable, A1 Keyboard A31P13 (part of A1)
A2DS1W1
a
Wire Cable, A2DS1 A4 Inverter (part of A2)
A4W1
a
Wire Cable, A4 Inverter A31P12 (part of A4)
A22W1
a
A22 Line Module A19 Power Supply (part of A22)
A22W2
a
A22 Line Module Chassis ground post on Rear Panel
and A19 Power Supply
(part of A22)
A25BW1
a
Wire Cable, A25B Highband Detector
Bias board
A26J12 (part of A25)
A32W1
a
Wire Cable, A32 10 MHz Crystal
Oscillator
A21P2 (part of A32)
B1W1
a
Wire Cable, B1 Fan A21P251 (part of B1)
W1 Front Panel (EXT 1) A11J401 8121–0628
W2 Front Panel (EXT 2) A11J402 8121–0628
W3 Front Panel (LF OUTPUT) A11J403 8121–0628
W4 Front Panel (ALC INPUT) A10J4 8121–0859
W5 Front Panel
(PULSE/TRIGGER GATE INPUT)
A11J201 8121–0625
W6 Front Panel (PULSE VIDEO OUT) A11J203 8121–0625
W7 Front Panel (PULSE SYNC OUT) A11J202 8121–0625
W8
for instruments with serial
prefix < US/MY5XXX3XXX
A3 Power Switch (DATA CABLE) A2 Display 8121–0165
for instruments with serial
prefix ≥ US/MY5XXX3XXX
A3 Power Switch (DATA CABLE) A2 Display 8121–0689
W9 A3P1 A31P11 8121–0614
W10 A9J3 A31J1031 8121–0624
W11 A9J4 A31J1021 8121–0624
W12 A9J5 A28J1 8121–0608
W13 A10J201 A30J6 8121–0624
