236 E8257D/67D, E8663D PSG Signal Generators Service Guide

Replaceable Parts

Hardware

Microcircuit Interface Deck Top View

Figure 2-26 E8257D & E8663D Microcircuit Interface Deck Top View

Figure 2-27 E8267D Microcircuit Interface Deck Top View

Table 2-14 Microcircuit Interface Deck Top View

Item No. Description Qty Part Number

1 Screw-Machine M3.0 x 14 CW-PN-TX 1 0515-0665
