232 E8257D/67D, E8663D PSG Signal Generators Service Guide

Replaceable Parts

Hardware

Disassembled A24 20GHz/40GHz Highband Coupler and A25B

Highband Detector Bias Board

(Options 503, 509, 513, 520, and 540)

Figure 2-22 Disassembled A24 20GHz/40GHz Highband Coupler and A25B Highband

Detector Bias Board

Table 2-10 Disassembled A24 20 GHz/40 GHz Highband Coupler and A25B Highband

Detector Bias Board

Item No. Description Qty Part Number

1 Coupler Bracket 1 E8251-00039

2 Washer Lock M2.0 2 2190-0654

3 Screw-Machine SM 256 .250 PN-PN 2 0520-0128

4 Screw-Machine M3.0 x 8 CW-PN-TX 4 0515-0372
