E8257D/67D, E8663D PSG Signal Generators Service Guide 229

Replaceable Parts

Hardware

Disassembled A32 10 MHz Crystal Oscillator (Option UNR/UNX/UNY

and Instruments with Serial

Prefixes ≥ US4805/MY4805)

Table 2-8 Disassembled A32 10 MHz Crystal Oscillator (Option UNR/UNX)

Item No. Description Qty Part Number

1 C-Bracket 1 E8251-00040

2 Shock Mount 3 1520-0205

3 Flathead Washer 3 3050-0105

4 Screw-Machine 4.0 x 40 .250 3 2200-0103

5 L-Bracket 1 E8251-00041

6 Screw-Machine M3.0 x 8 CW-PN-TX 2 0515-0372

7 Nut-Hex M3.0 (line module ground) 1 0535-0031

8 Screw-Machine M3.0 x 8 CW-PN-TX 2 0515-0372
