244 E8257D/67D, E8663D PSG Signal Generators Service Guide

Replaceable Parts

Hardware

Main Chassis with Inside Cover and Right-Side Support Wall

Table 2-20 Main Chassis with Inside Cover and Right-Side Support Wall

Item

No.

Description Qty Part Number

1 Main Chassis Inside Top Cover (E8257D & E8663D) 1 E8251-00342

Main Chassis Inside Top Cover (E8267D) 1 E8251-00208

2 Screw-Machine M3.0 x 08 FL-TX (inside top cover to main chassis and rear panel) 9 0515-0430

3 Screw-Machine M3.0 x 08 CW-PN-TX (rear panel to right-side support wall) 3 0515-0372

4 Screw-Machine M3.0 x 08 FL-TX (microcircuit interface deck to right-side support

wall)

6 0515-1035

5 Right-Side Support Wall 1 E8251-00014

6 Microcircuit Interface Deck (E8257D (E8663D) 1 E8251-00004

Microcircuit Interface Deck (E8267D) 1 E8251-00303

7 E8257D & E8663D Main Chassis 1 E8251-60354

E8267D Main Chassis 1 E8251-60350
