224 E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Hardware
Disassembled Front Panel View
Table 2-6 Disassembled Front Panel View
Item No. Description Qty Part Number
1 Front Panel Frame
light color
dark color
1
1
E8251-20102
E8251-20672
2 Gasket RFI Round Mesh .125 inch 1 8160-0660
3 Gasket RFI Round Mesh .062 inch 1 8160-0723
4 Velcro Attachment 1 0510-1303
5 Glass Filter 70% Xmt 1 4330-6704
6 Rubber Keypad Analog (E8257D & E8663D)
(for instruments with serial prefix < US/MY5644)
1
E8251-40006
a
a. If this part number is out of stock, you can order the part number listed for instruments with serial pre-
fixes
≥ US/MY5644
Rubber Keypad Analog (E8257D & E8663D)
(for instruments with serial prefix ≥ US/MY5644)
light color
dark color
1
1
E8251-40207
E8251-40209
Rubber Keypad Vector (E8267D)
light color
dark color
1
1
E8251-40208
E8251-40210
7 Bracket Filter 1 E4400-00009
8 Screw-Machine M3.0 x 08 FL-TX 14 0515-1227
9 Cable Retainer Clip 3 1400-1439
10 Sub Panel 1 E8251-00009
11 Screw-Machine M3.0 x 06 CW-PN-TX 17 0515-0372
12 Screw-Machine M3.0 x 08 FL-TX 1 0515-1035
