226 E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Hardware
Disassembled Rear Panel View
Table 2-7 Disassembled Rear Panel View
Item No. Description Qty Part Number
1 Rear Panel (E8257D & E8663D), Serial prefix < 4829 1 E8251-00020
Serial prefix > 4829 1 E8251-00353
Rear Panel (E8257D & E8663D) Option 1EM, Serial prefix < 4829 1 E8251-00013
Serial prefix > 4829 1
Rear Panel (E8267D), Serial prefix < 4829 1 E8251-00021
Serial prefix > 4829 1 E8251-67365
Rear Panel (E8267D) Option 1EM, Serial prefix < 4829 1 E8251-00022
Serial prefix > 4829 1 E8251-67366
2 Screw-Machine M3.0 8 CW-PN-TX
(mounting screws for rear-panel and rear struts)
E8257D & E8663D
E8267D
11
14
0515-0372
3 Screw-Machine M3.0 14CW-PN-TX (screw to mount B1 fan to rear-panel) 4 0515-0665
4 Beveled Washer (fan) 4 3050-1628
5 Grommet (fan) 4 0400-0356
6 Nut-Hex 1/2-28 (6 BNC connectors on rear-panel board) 6 2950-0054
7 Washer Lock .505ID (6 BNC connectors on rear-panel) 6 2190-0068
8 Nut-Hex 15/32-32 (10 MHz In/Out BNC connectors)
E8257D & E8663D
E8267D
9
26
2950-0035
9 Washer .490ID (10 MHz In/Out BNC connectors)
E8257D & E8663D
E8267D
9
26
3050-1919
10 Rear-Panel BNC Hole Plug (E8267D) 1 6960-0002
11 Standoff Screw-Hex .321I 4-40ss (Auxiliary Interface and SMI)
E8257D & E8663D
E8267D
4
6
0380-2079
12 Split Lock Washer .115ID 4 (Auxiliary Interface and SMI)
E8257D & E8663D
E8267D
4
6
2190-0003
13 Standoff Screw-Hex .327 6-32 (GPIB interface) 2 0380-0644
14 Split Lock Washer .194ID 10 (GPIB interface) 2 2190-0577
15 Screw-Machine M3.0 8 FL-TX (line module) 2 0515-1035
