E8257D/67D, E8663D PSG Signal Generators Service Guide 227

Replaceable Parts

Hardware

Figure 2-18 E8257D/E8663D Disassembled Rear Panel View

16 Right Rear Strut (E8257D & E8663D) 1 E8251-00006

Right Rear Strut (E8267D) 1 E8251-00308

17 Left Rear Strut (E8257D & E8663D) 1 E8251-00030

Left Rear Strut (E8267D) 1 E8251-00200

18 Shouldered Washer (E8267D) 1 00310-48801

Table 2-7 Disassembled Rear Panel View

Item No. Description Qty Part Number
