210 E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Cables
W14 A10J5 A23J104 8121–0627
W15
for instruments with serial
prefix < US/MY5644
A10J3 A25 40 GHz Highband Detector
8121–0900
b
for instruments with serial
prefix ≥ US/MY5644
A10J3 A25 20/40/50/67 GHz
Highband Detector
8121-2775
W16 A11J204 A12 Pulse Modulator Board 8121–0623
W17 A11J205 A30J7 8121–0626
W18 A18J1 A21J3 8121–0617
W19 A18J2 A26J30 8121–0619
W20 A20J1 A26J20 8121–0677
W21 A31J1043 Rear Panel (10MHz OUT) 8121–0622
W22 A31J1042 Rear Panel (10MHz IN) 8121–0622
W23 A21J2 A31P241 8121–0611
W24
for instruments with serial
prefix < US/MY5644
Semi–Rigid Cable, A24 20 GHz
Highband Coupler (output)
AT1 115 dB Mechanical Attenuator
(Option 1E1)
E8251–20025
b
for instruments with serial
prefix ≥ US/MY5644
Semi–Rigid Cable, A24 40 GHz
Highband Coupler (output)
AT1 115 dB Mechanical Attenuator
(Option 1E1)
E8251–20579
W25 Semi–Rigid Cable, AT1 (output) 2.4 mm RF Output adapter
(Option 1E1)
E8251–20582
W26
(Options 532 and 540)
Semi–Rigid Cable, A24 40 GHz
Highband Coupler (output)
2.4mm RF Output adapter (models
without Option 1E1)
E8251–20035
W27 Semi–Rigid Cable, A23 Lowband
Coupler/Detector
A30J3 E8251–20031
W28 A23J100 A26J15 8121–0616
W29 A27J10 A26J33 8121–0613
W30
(Option 540)
A27J2 A24 Highband Coupler (input) E8251–20578
W31
(Option 540)
A27J3 A30J2 E8251–20023
W32
(Option 540)
A27J1 A30J4 E8251–20022
Table 2-4 (Continued)
Reference Designator Input Output Part Number
