E8257D/67D, E8663D PSG Signal Generators Service Guide 211
Replaceable Parts
Cables
W33 A26J32 A29J10 8121–0613
W34 A26J31 A30J10 8121–0613
W35 A26J10 A31P201 8121–0615
W36 Ribbon Cable, AT1 90 dB/115 dB
Mechanical Attenuator
A26J13 8121–0982
W37
(E8257D & E8663D)
Semi–Rigid Cable, A23 Lowband
Coupler/Detector
A31 Motherboard (Output) E8251–20225
W38
(E8257D & E8663D)
Semi–Rigid Cable, A28 YIG Oscillator
(output)
A29J1 E8251–20014
W39
for instruments with serial
prefix < US/MY5644
A29J4 A31 Motherboard (Sampler)
E8251–20343
b
for instruments with serial
prefix ≥ US/MY5644
A29J4 A31 Motherboard (Sampler) E8251–20592
W40 A29J3 A31 Motherboard (Frac–N) E8251–20224
W41
(E8257D & E8663D)
A29J2 A30J1 E8251–20017
W42 Semi–Rigid Cable, A31 Motherboard
(Sampler)
A31 Motherboard (Reference) E8251–20226
W43 Semi–Rigid Cable, A31 Motherboard
(Frac–N)
A31 Motherboard (Output) E8251–20226
W44 A31J1051 A31J1122 8121–0620
W45 A31J1055 A31J1121 8121–0620
W46 Semi–Rigid Cable, A31 Motherboard
(Sampler)
A31 Motherboard (Frac–N) E8251–20029
W47 A32J1 A31J1041 8121-0621
W48 A32J2 Rear Panel (10 MHz EFC) 8120-6839
W49
(E8267D)
Front Panel (I IN) A13J7 8121-0901
W50
(E8267D)
Front Panel (Q IN) A13J8 8121-0901
W51
(E8267D)
Front Panel (DATA) A31J500 8121-0628
W52
(E8267D)
Front Panel (DATA CLOCK) A31J501 8121-0628
Table 2-4 (Continued)
Reference Designator Input Output Part Number
